UDR ( Dream Router )

The device is a compact desktop UniFi appliance measuring Ø110 x 184.1 mm (4.3 x 7.3") and supports the full UniFi Application Suite, including Network, Protect, Access, Talk, and Connect, managing over 20 UniFi devices and multiple cameras (5 HD, 2 2K, 1 4K) with 150+ simultaneous users. It features one GbE WAN port, with a total port layout of 1 GbE RJ45 and 5 (2 PoE) ports supporting 1G/100M/10M speeds, IDS/IPS throughput of 1 Gbps, and a coverage area of 140 m² (1,500 ft²). Security includes a stateful firewall, application-aware Layer 7 firewall, DPI, content filtering, intrusion prevention (IPS/IDS), ad blocking, 20,000+ IDS/IPS signatures with CyberSecure, and VLAN/subnet-based traffic segmentation. VPN and SD-WAN support includes license-free SD-WAN, site-to-site VPN, IPsec, OpenVPN, WireGuard, L2TP, and Teleport zero-configuration VPN, with identity endpoint one-click setup. Networking features include OSPF dynamic routing, advanced QoS, mDNS, NAT options, integrated RADIUS with RadSec, LTE backup, internet quality reporting, MAC table of 1,000 entries, policy-based WAN/VPN routing, customizable DHCP, IPv6 support, and IGMP proxy.

The integrated WiFi supports 802.11a/b/g/n/ac/ax (WiFi 6) with 5 GHz throughput of 2.4 Gbps, 2.4 GHz throughput of 600 Mbps, 4x4 MU-MIMO, maximum TX power of 26 dBm, and WPA-PSK/WPA-Enterprise security. Hardware includes a built-in 128 GB SSD, microSD expansion slot, 40W PoE budget with 15.4W per port, universal AC input (100–240V), internal 50W AC/DC power supply, dual-core Arm Cortex A53 1.35 GHz processor, 1.2 kg weight, polycarbonate enclosure, and a 0.96" status display. Management can be done via Ethernet, Bluetooth, or button, and it operates in -10 to 45°C with 5–95% humidity, is NDAA compliant, and certified CE, FCC, IC, Anatel. Software features include 802.1Q VLAN and guest traffic isolation.
